OGS-4

ر.س10.00

Unit OGS-4
Theoretical output Pcs/hr 1800
Volume L 3
Max. height mm 360
Max. diameter mm 105
Number of cavities / 2
Mould plate dimension(LxH) mm 490×405
Mould thickness mm 220
Mould opening stroke mm 180
Power 220-380V/50-60Hz
Total power KW 21
Heating power KW 20
Main body dimension(LxWxH) M 1.5×0.65×2.0
Main body weight KG 550
Preform Autoloader(LxWxH) M 1.8×0.60×1.4
Preform Autoloader weight KG 350



Add to Wishlist
Add to Wishlist

Additional Information

Features:

  • Double crank arm for mold locking reaches high mold-locking strength and flexible action.
  • Use PLC for control (time relay control optional), easy repair, low cost, with the time controllable accurately in 0.01s..
  • The gas circuit consists of moving and blowing so as to satisfy the different air demand of them.
  • The far-infrared heater uses a way of conversion self-rotating heating and the rail revolution makes the heating even, quick and reliable.
  • Every heating lamp has independent temperature control device, to get ideal preform heating effect 6.The direction of the heating lamp is adjustable upon different preforms.
  • Only need one operator, do not need special training. Simple installing and starting.
